Ultra EFIS AvMap

AvMap Ultra features an ultra-bright 3.5" LCD screen, readable even in sunlight. It is compact (78 mm) and ultra-light (only 230 g, compared with the market average of around 700 g).

Mounted in a 79.5 mm slot (standard size), the AvMap Ultra can be easily installed on your dashboard and connected to the external GPS receiver (included) and Pitot-static aircraft system to provide reliable, advanced ADAHRS data.

The AvMap Ultra contains solid-state gyroscopes, accelerometers, magnetic field sensors, air data sensors and the drone navigation motion processor, making it the most compact, reliable and complete EFIS of its type.

It is virtually insensitive to temperature variation (from -20°C to +70°C).

The AvMap Ultra also provides backup navigation: on the HSI screen you can select from the preloaded Jeppesen database an airport (ARPT), VOR and NDB as your navigation point.

AvMap Ultra can display two different pages on its 3.5" screen: PFD and HSI (pages can be easily changed using the rotor knob).

The EFIS PFD screen displays:
* Attitude (roll, pitch and heading)
* Pitot system airspeed - static
* Pitot system altitude - static
* Vertical speed
* G- meter
* Compass

EFIS HSI screen displays: current position, distance, indications, radials to navigation reference points and approximate wind data.

The EFIS Ultra contains an internal world magnetic model for calculating local magnetic declination. EFIS Ultra can calculate position and ground speed, even in the absence of GPS, with degraded quality.

Technical specifications:

Hardware :

- Dimensions: 95 x 95 x 78 mm
- Diameter: 77.5 mm (installation diameter 79.5 mm)
- Weight: 230 g
- Display: 3.5 " - 320 x 240 pixels, 500 cd/m2 brightness
- 3-axis gyroscopes, accelerometer and magnetometer
- Acceleration range ( 3-axis ): + / - 8 g
- Rotation range: + / - 1600 deg / s
- Air data sensors : 10 to 215 kts range , -1000 to 40000 ft
- UAV processor Navigation ® Motion
- 1.5 m power cable ( 10/35 VDC )
- 3 RS- 232 serial ports
- Consumption @ 12 V DC : 100 mA nominal
- GPS receiver cable U - Blox NEO 6Q with 59 " (1.5 m)

Software :

- data fusion capability
- Pitot system speed and altitude - static
- Attitude (roll, pitch and heading and sideslip)
- Wind indicator
- altimeter, reference position, reference values V - aircraft specific speed
- exceptional navigation capability in the event of GPS signal loss
- Equipped with Jeppesen databases (APT , VOR , NDB) for emergency navigation. 4 coverages available: Europe-Africa , North America , South America , and Asia-Australia .

Update available + instructions for versions lower than v3.14 in the download section
